| PERFORMANCE DATA | |
| Contact resistance | 30mΩ Max |
| Insulation resistance | 100MΩ Min |
| Dielectric strength | 500 VAC rms 60HZ. 1min |
| Durability | after 200 insertions Contact Resistance 30mΩ Max |
| NOTE | |
| FCC test condition are satisfied Material is UL Approved UL & cUL Approved(DUXR2)(DUXR8) |
| MECHANICAL | |
| Mating force | 22.24N Max |
| Unmating force | 44.48N Max |
| Retention strength | 76N Min |
| MATERIALS | |
| Housing | PBT, NY66, LCP Resin, UL94V-O Grey,White,Natural,Blue |
| Contact wire | Phosphorous bronze alloy. plated Hard gold(F, 15, 30, 50 M-IN) over Nickel |
