| Electrical Efficiency | |
| Voltage rating | 30VAC(rms) |
| Current rating | 1A |
| Contact resistance | 30mΩ Min. |
| Insulation resistance | 1000 MΩ Min. |
| Contact Capacitance | 2pF Max. |
| Material and Finish | |
| Housing | PBT, Ny66, LCP Resin, UL94-V0 Rated |
| Contact plate | Phosphorus bronze alloy Plated Hard gold over Nickel |
| EMI Shield | ¾ Hard Brass. Ni or Tin plated |
| Mechanical Efficiency | |
| Durability | 1500 cycles |
| Mating force | 35N Max. |
| Unmating force | 10N Min. |
| Features | |
| – Raised design provides easy insertion and withdrawal, and guarantee even high reliability – Design of three certain restraints provides robustious structure. – Gold plated contact to ensure low contact resistance. – All materials are UL94-V0 grade fire retardant. – Up to 5 meters per cable segment. To make sure your connections are perfect every time. |
