| ELECTRICAL EFFICIENCY | |
| Contact Resistance | 30mΩ Max. |
| Insulation Resistance | 100MΩ Min. |
| Withstanding Voltage | 1000 VAC rms 60HZ, 1min |
| Durability | after 200 insertions Contact Resistance 210MΩMax |
| MECHANICAL | |
| Retention force | 7.7kg Min |
| Crimping strength | 2.2kg Min |
| Leadwire breaking strength | 6kg Min(with PVC) |
| Contact mating force | 350gr Min(2P), 500gr Min(4P), 800gr Min(6P),1000gr Min(8P) |
| Termination stripping | 7.7kg Min |
| MATERIALS | |
| Plastic | ABS or Polycarbonate Resin |
| Lead wire | 26 AWG, 7 strand, UL1061 wire, Solid wire,YL, GL, RD, BK, WH, BL |
| Contact wire | Phosphorus bronze alloy Plating Hard gold(15, 30, 50M-IN) over Nickel |
| Terminal | ¾ Hard Brass. Tin plating |
| Screw | Steel or Brass Nickel or Zn plating |
| Steel cover | Steel or Stainless steel Polishing surface of Hair line,Clear vinyle of wrapper |
| Bracket | Steel plate Zn or Nickel plating |
