| ELECTRICAL EFFICIENCY | |
| Contact resistance | 30 mΩ Max. |
| Insulation resistance | 100 ㏁ Min. |
| With standing Voltage | 500 VAC rms 60HZ. 1min |
| MECHANICAL | |
| Durability | 1500 cycles |
| Mating force | 39.2N Max. |
| Unmating force | 4.9N Min., 39.2N Max. |
| MATERIALS | |
| Housing | PBT, Ny66, LCP Resin,UL94-V0 Rated |
| Contact plate | Phosphorus bronze alloy Plated Hard gold over Nickel |
| EMI Shield | ¾ Hard Brass. Ni or Tin plated |
| FEATURES | |
| – Raised design provides easy insertion and withdrawal, and guarantee even high reliability – Design of three certain restraints provides robustious structure. – Gold plated contact to ensure low contact resistance. – All materials are UL94-V0 grade fire retardant. – Up to 5 meters per cable segment. – To make sure your connections are perfect every time. |
